AC Speed Control Motor
SCM590KUA-5H50B
Combi geared motor
สินค้านี้ไม่มีจำหน่ายอีกต่อไป
| การจำแนกประเภทผลิตภัณฑ์ | ชื่อผลิตภัณฑ์ | รายการราคา | วันที่จัดส่ง |
|---|---|---|---|
| Combi geared motor | SCM590KUA-5H50B | THB 13,888 | สินค้าที่เลิกผลิตแล้ว (31.3.2026 discontinued) |
รวม
- Motor: None
Gearhead: Mounting Screws, Parallel Key, Safety Cover
ข้อมูลเฉพาะ
ขนาด
Motor/Gearhead
ดาวน์โหลดข้อมูล
ข้อมูลเฉพาะอื่น ๆ
Permissible Radial Load and Permissible Axial Load of Gearhead
| Gear Ratio | 10 | 15 | 20 | 30 | 50 | 100 | 200 | ||
|---|---|---|---|---|---|---|---|---|---|
| Permissible Radial Load [N] *1 | Hollow Shaft*2 | 10 mm From Mounting Surface | 415 | 554 | 692 | 923 | 1112 | 1196 | 1291 |
| 20 mm From Mounting Surface | 363 | 484 | 605 | 806 | 971 | 1045 | 1127 | ||
| Solid Shaft | 10 mm From the End of the Output Shaft | 378 | 504 | 630 | 840 | 1011 | 1089 | 1174 | |
| 20 mm From the End of the Output Shaft | 481 | 641 | 802 | 1069 | 1287 | 1385 | 1495 | ||
| Permissible Axial Load [N] | 108 | 147 | 186 | 245 | 294 | 324 | 343 | ||
- *1
- The load position is shown below.
- *2
- For calculations of the radial load from every distance for the hollow shaft type, refer to "Permissible radial load calculation for hollow shaft type" below.
Calculating the Permissible Radial Load for Hollow Shaft Type
The formula for calculating the permissible radial load varies depending on the mechanism.
มาตรฐาน
Regulations and Standards Materials
Documents about compliance with regulations and standards can be downloaded from the "Data Download" tab on the product details page.
(The types of files available for download vary by product.)
Explanations of the Global Laws, Regulations and Standards can be found here.
Information about our compliance with safety standards for each of our product models can be found here.
Hazardous Substances
The product does not contain any substances (10 substances) exceeding the regulation values of the RoHS Directive (2011/65/EU, 2015/863/EU).
