AC Speed Control Motors Motor for "Motor and Driver Package"

MBM540-011

การจำแนกประเภทผลิตภัณฑ์	ชื่อผลิตภัณฑ์	รายการราคา	วันที่จัดส่ง
Motor	MBM540-011	THB 9,649	50 Working Days

• This product is a motor only (component) of the speed control motor and controller package.

ข้อมูลเฉพาะ

Item	Specifications
Insulation Resistance	After rated operation at normal ambient temperature and humidity, the value measured with a 500 VDC megger between the motor windings and the case is 100 MΩ min.
Dielectric Strength	After rated operation at normal ambient temperature and humidity, no abnormality is observed even if 50 Hz, 1.5 kVAC is applied between the motor windings and the case for 1 minute.
Temperature Rise	The value measured by the thermometer method after rated operation is 60 °C max.
Thermal Class	120(E)
Operating Ambient Temperature	-10~+50°C (Non-freezing)
Operating Ambient Humidity	85 % max. (Non-condensing)
